What can I do with Orange Pi 2G-IOT?
Build…
- A computer
- A wireless server
- Games
- Music and sounds
- HD video
- A speaker
- Android
- Scratch
- Pretty much anything else, because Orange Pi 2G-IOT is open source
Who’s it for?
Orange Pi 2G-IOT is for anyone who wants to start creating with technology – not just consuming it. It’s a simple, fun, useful tool that you can use to start taking control of the world around you.
Hardware specification | ||
| CPU | ARM Cortex-A5 32bit | |
| GPU | Separate graphic processor, Vivante’s GC860 support OpenGLES1.1/2.0 support OpenVG1.4 support DirectFB support GDI/DirecShow 30M Triangle/s, 250M Pixel/s | |
| Memory (SDRAM) | Integrated 256MB LPDDR2 SDRAM | |
| Onboard Storage | TF card / Integrated 512MB 8Bit 1.8V 4K SLC Nand Flash | |
| Onboard WIFI+BT | RDA5991, WIFI+BT | |
| 2G model | The four frequency single card GSM/GPRS Dedicated accelerators SIM card | |
| Video Input | A CSI input connector Camera Supports 8-bit YUV422 CMOS sensor interface Supports CCIR656 protocol for NTSC and PAL Supports SM pixel camera sensor Supports video capture solution up to 1080p@30fps | |
| Audio Input | MIC, 3.5 mm Jack | |
| Video Outputs | LCD | |
| Audio Outputs | 3.5 mm Jack, FM, SPEAK（Optional） | |
| Power Source | USB OTG can supply power Battery input can supply power（Optional） | |
| GPIO(1×3) pin | UART, ground. | |
| USB 2.0 Ports | One USB 2.0 HOST, One USB 2.0 OTG | |
| Buttons | Power Button(SW602) | |
| Low-level peripherals | 40 Pins Header,compatible with Raspberry Pi B+ | |
| LED | Power led | |
| Supported OS | Android, Ubuntu, Debian, Raspbian Image | |
Interface definition | ||
| Product size | 67 mm × 42mm | |
| Weight | 35g | |
