Temperature Sensor Modules
CJ1WTS562 (Temperature Sensor Module Screw Terminal Connection)
Omron Temperature sensor module is suitable for use with cj1 series programmer controllers
Highlights/Features:
Omron Temperature sensor module is suitable for use with cj1 series programmer controllers These temperature sensor units are classified as digital I/O units when considering I/O allocations and will take digital I/O points from the total allocation for a CJ1M CPU. The number of I/O points is DIP switch selectable as follows; configured for 1 - 3 inputs takes 48 digital I/O points, configured for 4 inputs takes 64 digital I/O points and configured for 5 - 6 inputs takes 96 digital I/O points.
CJMCU-175 (Digital Temperature Sensor Module)
General Features:
CJMCU-175 Digital Temperature Sensor TMP175 27 Address
Digital output: SMBusTM, two-wire and I2C interface compatibility
Resolution: 9 to 12 digits, user selectable
Wide supply voltage range: 2.7V to 5.5V
TMP175 allowing up to 27 devices on a bus member.
It is a negative temperature desired coefficient thermistor (NTC) and positive temperature coefficient (PTC) for generation
The device provides a typical Ā±1Ā°C accuracy without calibration or external component signal conditioning .
The on-chip 12-bit analog -to- digital converter (ADC) provides resolution down to 0.0625Ā°C.
DHT11 (Temperature and Humidity Sensor Module)
DHT11 Temperature and Humidity Sensor Module with LED Power Supply Indicators
Features:
- Can detect surrounding environment of the humidity and temperature
- DHT11 sensor adopts
- Humidity measurement range: 20%-95%, humidity measurement error: +-5%
- Temperature measurement range: 0 -50 ;measurement error: +-2 degrees
- Working voltage 3.3 V-5 V
- Output form: digital output
- Has fixed bolt hole and easy installation
- PCB size: 3.1cm x 1.4cm
DHT22- (Temperature and humidity sensor)
Product description:
The DHT22 module is designed to measure the temperature and humidity of the atmosphere. The difference from the younger model (DHT11), The DHT22 has a wide range and a high precision determination of temperature and humidity. The sensor works on the OneWire bus, which makes it possible to connect it to the Arduino only three wires ( two of which are POwer supply). Low power consumption allows you to install it on stand-alone devices.
GY-AMG8833 (IR 8×8 infrared camera array temperature sensor module)
HTG3515CH- (Voltage Output Temperature and Humidity Sensor)
Voltage Output Temperature and Humidity Sensor HTG3515CH
Relative Humidity and Temperature Module
SPECIFICATIONS:
- Suitable for small bulk assembly
- Product free from Lead, Cr (6+), Cd and Hg. Compliant with RoHS
- Full interchangeability. Better than +/-3%RH and +/-0.25Ā°C
- Humidity calibrated within +/- 3% RH @ 55% RH
- Temperature measurement through NTC direct output
Based on the rugged HUMIREL humidity sensor, HTG3515CH is a dedicated humidity and temperature plug and play transducer designed for OEM applications where a reliable and accurate measurement is needed. Direct interface with a micro-controller is made possible with the moduleās humidity linear voltage and direct NTC outputs. HTG3515CH is designed for high volume and demanding applications.
KY-028 -Temperature sensor module (Digital)
Product Features:
- Using the NTC thermistor sensor , good sensitivity.
- The comparator output signal is clean, good waveform , driving ability , more than 15mA.
- Adjust the temperature distribution position detection threshold.
- The working voltage: DC 3.3V-5V.
- The output format : digital switching outputs ( 0 and 1 )
- A fixed bolt holes for easy installation.
- Using a wide voltage LM393 comparator.
MAX6675-(Temperature Sensor With Thermocouple Cable)
MAX6675 Module + K Type Thermocouple Sensor:
The MAX6675 performs cold-junction compensation and digitizes the signal from a type-K thermocouple. The data is output in a 12-bit resolution, SPIā¢-compatible, read-only format. This converter resolves temperatures to 0.25Ā°C, allows readings as high as +1024Ā°C, and exhibits thermocouple accuracy of 8LSBs for temperatures ranging from 0Ā°C to +700Ā°C.
SHT31 (Digital Temperature and Humidity Sensor Module)
General Features:
- Highly reliable, accurate and quick response time
- I2C interface
- Well calibrated, linearized, compensated for digital output
- Highly abstracted development library
- Input voltage (VCC): 3.3 volts or 5 volts
- I/O Logic Level : 3.3 volts or 5 volts based on VCC
- Operating Current : 100 Ī¼A
- Operating Temperature : -40ā125 ā
- Temperature Sensor Range : -40ā125 ā, with Ā±0.3Ā°C accuracy
- Humidity Sensor Range : 0% - 100%(Relative Humidity), with Ā±2% accuracy
- Sensor Chip : SHT31
- I2C
TMP006 (Contact-less Infrared Temperature Measurement)
The TMP006 works with 3v to 5v, so it can be used with most microcontrollers without the need for a level shifter. It connects via the i2c bus and is addressable so you can have up to 8 TMP006 sensors on the same bus.
Features:
- 20mm x 20mm (board w/o headers)
- Uses I2C 7-bit addresses between 0x40 and 0x47, selectable with jumpers
- Interface Type : I2C Arduino driver module
