Overview

Feature
1. High frequency, high precision, high frequency stability and fast warm up
2. Low phase noise, low power consumption, low supply voltage and low drive level
3. Wide operating temperature range
4. DIP14 package and DIP8 pacage
5. RoHS compliant and Pb-free

Detailed Description

Application
1. OCXO works as a general crystal oscillator for various circuits to generate oscillation frequency.
2. It is a clock generator that works together with other electronic components to offer standard pulse signals for digital circuits.
3. It is also a quart crystal oscillator for MCU, CTV, VTR and watch.

Technical Data of OCXO
1. Crystal cut: SC/AT
2. Frequency range: 10MHz-100MHz
3. Operating temperature range: -40℃~ 85℃
4. Frequency-temperature characteristic: 20ppb~100ppb (AT-cut), 5ppb~20ppb (SC-cut)
5. Supply voltage: 3.3V/ 5.0V/ 12.0V
6. Warm-up power: 5W
7. Output waveform: Sine wave
8. Size: 25×25×12mm (DIP8), 36×27×14 (DIP14)
