Desktop Lead-Free Reflow SMD Soldering Oven [QS-5188]

Get Quotation!

Available in Lahore Office, Pakistan.

Qinci SMT Soldering Oven

The main technical parameters of lead-free desktop reflow soldering machine QS-5188 in Pakistan

1. Input power supply: AC220V
2. Working frequency: 50~60Hz
3. Input maximum power: 2400W
4. Heating method: infrared radiation and hot air mixed heating method
5. Operating system: QS-5188 bilingual operating system in Chinese and English
6. Working mode: general SMT soldering, low temperature lead-free SMT soldering, medium temperature lead-free SMT soldering, high temperature lead-free SMT soldering, SMT red glue curing, device packaging curing, drying and baking and other modes, users can set multiple according to their needs
7. Drawer working area: 300x400mm
8. The height of the working disk space: 60mm
9. Working plate load: 7.5kg
10. Dimensions: 500x372x325mm
11. Packing box specifications: 600x500x400
12. Machine weight: 30kg
13. Brand: Qinsi
14. Company: Qinci Technology Co. Ltd
