Optical Finger Print Sensor- FPM10A

Applications

• Biometric Identification
• Security systems
• Identification systems
• Electronic Voting Systems
• Que management systems
• Mobile SIM issuing systems

Technical Specifications

• Power supply voltage: DC 3.6~6.0V
• Supply current: working current: <120mA
• Peak current: <140mA
• The time of fingerprint image input: < 1 seconds
• The window size: 14 x 18 mm
• Profile: 256 bytes
• Template file: 512 bytes
• Storage capacity: 1000
• False accept rate (FAR): < 0.001% (safety grade 3)
• FRR (FRR): < 1% (safety grade 3)
• The search time: < 1 seconds (1:500, mean)
• Computer interface: UART (TTL logic level)
• The communication baud rate (UART): (9600 x N) BPS where N=1 ~ 12 (the default value of N=6, namely 57600bps)
• Working environment: temperature: -20°C to +50°C
• Relative humidity: 40%RH to 85%RH (no treatment)
• Storage conditions: temperature: -40°C to +85°C
• Relative humidity: < 85%H (no treatment)
• Dimensions (L * W * H): 56 x 20 x 21.5mm

Pinouts

1. VCC (RED)
2. GND (BLACK)
3. RXD  (YELLOW)
4. TXD (GREEN)
