PIC18F2685-I/SO
Features:
- ECAN™ nanoWatt Features Internal Oscillator Self-Programming 40 MHz Max Speed LIN USART
Description
Specifications:
| Attribute | Value |
|---|---|
| Family Name | PIC18F |
| Package Type | SOIC |
| Mounting Type | Surface Mount |
| Pin Count | 28 |
| Device Core | PIC |
| Data Bus Width | 8bit |
| Program Memory Size | 1.024 kB, 96 kB |
| Maximum Frequency | 40MHz |
| RAM Size | 3.328 kB |
| Number of PWM Units | 1 |
| ADC Channels | 8 |
| Number of SPI Channels | 1 |
| Typical Operating Supply Voltage | 4.2 → 5.5 V |
| Width | 7.5mm |
| Program Memory Type | Flash |
| Number of Timers | 4 |
| Number of ADC Units | 1 |
| Number of USART Channels | 1 |
| ADCs | 8 x 10 bit |
| Timer Resolution | 8 bit, 16 bit |
| ADC Resolution | 10bit |
| Minimum Operating Temperature | -40 °C |
| Number of CAN Channels | 1 |
| Timers | 1 x 8 bit, 3 x 16 bit |
| Instruction Set Architecture | RISC |
| Dimensions | 17.9 x 7.5 x 2.35mm |
| Length | 17.9mm |
| Pulse Width Modulation | 1(CCP) |
| Maximum Operating Temperature | +85 °C |
| Height | 2.35mm |
| Number of I2C Channels | 1 |
