TJC 7 Inch HMI Touchscreen LCD Display – X3 Series TJC8048X370_011R AI Smart Resistive Touch Display – Commercial Grade
Original price was: ₨10,200.00.₨9,500.00Current price is: ₨9,500.00.
Basic Introduction:
- TJC- X3 Series
- 7 Inch Smart HMI Display
- USART HMI Resistive Touch
- Audio/Video animation
- Extended IOs
- Expandable memory
- Internal flash memory 16MB
- PC communication through USB-TTL converter
Best Price of TJC 7 Inch HMI Touchscreen LCD Display in Pakistan | X3 Series TJC8048X370-011R AI Smart Resistive Touch Display
Multifunctional HMI 7 inch Display Module with Serial Port USART
What is the Price of TJC 7 inch HMI LCD (TJC8048X370) in Pakistan today?
You can now purchase this TJC 7 inch display (X3 Series) for best prices from Techonics LTD, the wholesaler of TJC and Nextion in Pakistan.
Ideal to use with Arduino, Raspberry Pi, ESP32 or any of your favorite DEV Boards!
Technical Specifications TJC8048X370_011R:
Basic Parameters of TJC 7 Inch HMI
| parameter | data | Description |
| color | 65K(65536)color | 16-bit Color palette 5R6G5B |
| Dimensions | 181(L)×108(W)×9.3(H) | TJC8048X370_011R |
| Display size | 164.9mm(L)×100mm(W) | 800×480 Pixel mode |
| Visual size (AA) | 154.08mm(L)×85.92mm(W) | 800×480 Pixel mode |
| Resolution | 800×480 Pixel | Can be set to 480×800 |
| Touch-type | 4 Wire precision resistance type | |
| Number of touches | least 100 Million times | |
| Backlight mode | led | |
| Backlight life (average) | >30,000 hour | |
| brightness | 300nit | Can proceed 100 Level brightness adjustment |
| Net Weight | 258g |
Electrical performance parameters of TJC 7 Inch HMI Touchscreen Display
| Parameter | Test Conditions | Minimum | Typical value | Max | unit | |
| Operating Voltage | 4.65 | 5 | 6.5 | V | ||
| Working current | VCC=+5V, The maximum backlight brightness | – | 430 | – | mA | |
| SLEEP mode | 170 | mA | ||||
| Recommended power supply:5V 1A DC power supply | ||||||
Working environment and reliability parameters TJC 7 Inch (X3 Series)
| Parameter | Test environment | Minimum | Typical value | Max | unit |
| Operating temperature | 5V Under voltage, humidity 60% | -20 | 25 | 70 | °C |
| Storage temperature | – | -30 | 25 | 85 | °C |
| Working humidity | 25°C | 10% | 60% | 90% | RH |
| Three prevention treatment | – | – | no | – | – |
Interface performance parameters
| parameter | Test Conditions | Minimum | Typical value | Max | unit |
| Serial port baud rate | standard | 2400 | 9600 | 921600 | bps |
| Serial output level (TXD) | Output 1,Iout=1mA | 3.0 | 3.2 | – | V |
| Output 0,Iout=-1mA | – | 0.1 | 0.2 | V
|
|
| Serial input level (RXD) | Output 1,Iout=1mA | 2.0 | 3.3 | 5.0 | V |
| Output 0,Iout=-1mA | -0.7 | 0.0 | 1.3 | V | |
| Interface level | 3.3V/5V TTL Level(or 232 Level) | ||||
| Communication mode | 8,1,None | ||||
| User interface mode | 4Pin_2.54mm With lock | ||||
| SD Card interface | Have(FAT32 File format) maximum support 32G MicroTF/SD card | ||||
| Expand IO | no | ||||
| RTC | no | ||||
Memory characteristics
| Memory category | parameter | Minimum | Typical value | Max | unit |
| FLASH Memory | Font image storage space | 16 | MB | ||
| User store | EEPROM | 1024 | BYTE | ||
| Running memory(RAM) | Control/Variable storage space | 512 | KB | ||
| Serial command buffer | Serial command buffer | 1024 | BYTE |
Audio characteristics (optional)
| Speaker characteristics | parameter | Minimum | Typical value | Max | unit |
| power | 16 ohm 0.5W | 0.5 | W | ||
| Dimensions | Φ40 X 5.2H | mm |
Buy from Authentic, Use Authentic.
Techonicsltd, Pakistan’s no 1 wholesaler for HMI, HDMI LCDs, sensors, dev boards and moreover Mobile, Laptop, Tablet panel LCDs, and Other Spare Parts at wholesale prices! Get the best prices in Pakistan. Contact us now!
| Weight | 0.290 kg |
|---|---|
| Dimensions | 20 × 13 × 3 cm |
