Winsen ZH03A (Laser Dust particle Sensor Module)

ZH03A laser dust sensor module is a common type, small in size, using a laser scattering principle to detect dust particles in the air, with good selectivity and stability. It is easy to use, with UART Output and Analog Output.

Compare

Winsen ZH03A is a laser dust sensor which can detect PM1.0, PM2.5 and PM10 particles. Its small size and low price should make it a great add-on to volatile organic compounds (VOCs) and carbon dioxide (CO₂) sensors from FIGARO Engineering and Amphenol Advanced Sensors.

The air pollution in biggest cities is a growing problem. Regarding to World Health Organization (WHO) constant living in high concentrations of PM2.5 may lead to shorten of average life length. Even short exposure contributes to risk of developing cardiovascular and respiratory diseases.

Winsen ZH03A is ideal for portable and stationary air quality monitors, air purifiers, ventilation systems and smart home equipment.

Technical specifications:

Model: ZH03A

target detection: PM1.0, PM2.5, PM10

Output: UART Output (3 V TTL); DAC (0 ~ 2 V corresponds to 0-1000); PWM

Operating voltage: 4.5 V-5.5 V

Operating current: 70-140 (ma)

Response Time: ≤ 90 s

Operating temperature: -20 ~ 40 ℃

Size: 50 * 32.4 * 21mm

Features:

Zero speed alarm

real-time response

exact data

Minus resolution particle diameter 1.0 μm

Main applications:

It is widely used in portable instrumentation, air quality monitoring equipment, air purifiers, ventilation systems, air conditioning, and smart home equipment.
